Pallets · Special · Special pallets

Custom pallet

Custom pallet, article 5000, is developed for goods that do not fit a standard pallet. Dimensions, materials, load cases and special functions are defined around the product and handling. Plywood, chipboard, wood or plastic blocks can be used, and features such as pre-drilled holes can be added. The pallet is designed around the goods’ weight, centre of gravity, supports, lifting and stacking methods.

Article
5000
Price
Request a quote for the current price and availability

Would you like to review dimensions, load and handling? Book a meeting (Swedish)

Custom pallet • article 5000

A custom pallet designed around the goods and logistics

When standard formats, standard materials or an ordinary pallet construction are insufficient, dimensions, material and function can be adapted to the product. The specification starts from the load, handling, transport flow and the interfaces the pallet must fit.

Product specification

Verified product information for article 5000
ProductCustom pallet
Article number5000
CategoryPallets / Special / Special pallets
Dimensions and tolerancesThe format is adapted to the goods. Exact dimensions and critical tolerances are established in the quotation and drawing documentation.
Quote information: external dimensions of the goods, support surfaces, clearances and interfaces with critical tolerances.
Materials and componentsMaterial options include plywood, chipboard, wood and plastic blocks.
Quote information: load capacity, surface, environment, cleaning and any material restrictions.
Load and handlingLoad capacity is designed for the use; no general maximum value is published.
Quote information: weight, centre of gravity, static, dynamic or rack-supported load case, and lifting and stacking methods.
Special functionsPre-drilled holes and other product-specific construction details can be included.
Quote information: hole patterns, positions, fastenings, connection points and any drawings.
Quantity and production seriesSample quantity, order volume and delivery arrangements are defined for the project.
Information for a quote: required quantity, estimated annual volume and call-off pattern.
ExportPallets containing applicable solid wood can be heat-treated and marked according to ISPM 15 when required by the destination’s rules.
Quote information: destination country, constituent materials, transport route and documentation requirements.
Possible dimensionsLength and width 100–20 000 mm; height 10–1 000 mm. Dimension combinations and load capacity are designed for the project.
PriceRequest a quote for the current price and availability

Customisation and quote information

What can be customised in a custom pallet?

Article 5000 is manufactured with lengths and widths from 100 to 20 000 mm and heights from 10 to 1 000 mm. Dimension combinations and load capacity are designed around the goods and handling.

Construction and design

Deck boards, runners, blocks, materials and fixings are selected according to the goods' geometry, weight, support and handling.

Load capacity and load conditions

Custom load case

Designed around the goods

Engineered according to the goods’ weight, centre of gravity, support conditions, and lifting and stacking methods.

Robot cell with a wooden pallet at GLF’s production facility in Genarp.

Manufacturing and customisation

Manufacturing at GLF

CAD design and robotic nailing capability in Genarp.

Pallet lengths up to 1 600 mm on the production line; 800–3 000 mm in a separate pallet robot. The manufacturing method is selected for the construction.

Options: laser marking on plastic blocks and inkjet marking on wooden blocks, depending on the selected specification.

Genarp has pallet drying facilities for newly manufactured wooden pallets. Moisture level and any heat treatment are selected according to the product and transport requirements.

Production in Genarp →

The right details from the start

What we need to assess the solution

Clear requirements reduce the need for assumptions. Send a drawing or sketch with the goods information, even if every detail has not yet been established.

Request a tailored quote

Include in the enquiry

  • The goods’ length, width, height and weight
  • Centre of gravity, support surfaces and securing points
  • How the pallet will be lifted, stacked and stored
  • Static, dynamic or rack-supported load case
  • Quantity, estimated annual volume and call-off pattern
  • Destination country and any export requirements
  • PEFC requirements and documentation – see the PEFC checklist for pallet purchasing.

When a standard pallet does not fit

Common reasons to choose a custom pallet

Customisation must solve a specific problem in supporting, fastening or handling the goods.

Geometry

Goods outside standard formats

The pallet’s length, width and support surfaces can be adapted where a standard format does not properly support the product.

Interfaces

Holes, fastenings and supports

Pre-drilled holes and other construction details can be defined around the product’s connections and securing points.

Material

Combination to suit the requirements

Plywood, chipboard, wood and plastic blocks can be used where each material suits the specified function.

From requirements to a quote

How a custom pallet is defined

The project's risks and complexity determine whether a drawing review, prototype, trial production or specific testing needs to be included.

  1. 01

    Describe the goods

    Gather dimensions, weight, centre of gravity, support surfaces and sensitive components.

  2. 02

    Define the flow

    Specify lifting, stacking, storage, load securing, return flows and destination.

  3. 03

    Choose the construction

    Geometry, materials, blocks, hole patterns and other functions are adapted to the requirements.

  4. 04

    Verify where required

    Prototypes, pilot series or testing can be used where function and risk must be checked before series production.

  5. 05

    Finalise the specification

    Final dimensions, materials, load cases, quantities and requirements are documented for the quote and order.

Export and ISPM 15

Treatment and marking depend on material and destination

IPPC marking is not a general product certification. A custom pallet containing applicable solid wood may need heat treatment and ISPM 15 marking when required by the destination country’s rules. A pallet made entirely from processed wood, such as plywood or chipboard, is normally exempt. The destination may impose additional requirements, so always specify the market and materials in the quote information. See current information from the Swedish Board of Agriculture.

  • DestinationCountry and transport route are needed to assess current requirements.
  • MaterialSolid or processed wood affects whether ISPM 15 is relevant.
  • SpecificationsTreatment, marking and documentation are confirmed in the quote specification.

Related guidance and products

From custom pallet to complete packaging

Frequently asked questions

Frequently asked questions about custom pallets

What information is needed for a custom pallet quote?

Send the dimensions, weight, centre of gravity, lifting and securing points, planned load case, quantity and destination of the goods. Also specify required materials, hole patterns or other interfaces if already defined.

What dimensions can a custom pallet have?

Length and width are customised within 100–20 000 mm and height within 10–1 000 mm. Each construction is designed around the dimensions, weight, support points and handling of the goods.

Which materials can be used?

Material options include plywood, chipboard, wood and plastic blocks. The final combination is selected according to load, handling, environment and any export requirements.

How is a custom pallet’s maximum load determined?

Load capacity is designed for the specified use case. State whether the load is static, dynamic or rack-supported and how the pallet will be lifted, stacked and secured; the final value is confirmed in the specification.

Does a custom pallet need ISPM 15 marking for export?

This depends on the destination country's rules and the material. Solid-wood pallets may need heat treatment and ISPM 15 marking, while pallets made entirely from processed wood, such as plywood or chipboard, are normally exempt. Include the destination in your quote request so the requirement can be assessed.

Define your pallet requirements for a quote

Need a pallet outside standard formats?

Send the dimensions, weight, load case, quantity and destination for a proposal covering construction, materials and delivery arrangements.

Request a quote

Custom palletArt. 5000
Request a quote →
